label applicator

introduction

Applicable to circumferential labeling of various cylindrical products. Such as cosmetic bottles, shampoo bottles, shower gel bottles,medicine bottles, jam bottles, essential oil bottles, sauce bottles, wine bottles,mineral water bottles, beverage bottles, glue bottles,etc.

Send email

Chat now

share with:

Intelligent operation panel can help you control the machine easily.It can be set into English version,the working data like counting functions,delay time can be controlled by this panel.Beside two black rotary knobs can be used to control working speed.

The feeding inlet can be adjusted according to bottle diameter.This machine is suitable for φs 100mm bottles.The working speed of the conveyor can be adjusted as operators' need.This help to improve working efciency.

The electric eye can detect bottles once ,they pass through.The sensitivity regulator is designed to adjust the sensitivity of the electric eyes, prevent from missing bottles.

These three labeling wheels make bottles rotating and then finish labeling,ensure that there is no bubbles under labels. Ensure the labeling effect.This is suitable for double side labeling.

High quality motor,make the machine , work stably and can work for a long time.

Printer(Optional) :Mark the date, batch number and other information on the label to improve production efficiency

Paremeter

good quality, good after-sale service

Label applicator
Type	KY-150II
Label Quantity	One label at a time
Accuracy	±1mm
Speed	30~120pcs/min
Label size	Length20~300mm;Width15~100mm
Product size(Vertical)	Diameter30~100mm;height:15~300mm
Label requirement	Roll label;Inner dia 76mm;Outside roll≦250mm
Machine size and weight	L1200W800H500mm; 185Kg
Power	AC 220V ; 50/60HZ
Additional features	1.Can add the ribbon coding machine 2.Can add transparent sensor 3.Can add inkjet printer or laser printer

Application
